RCXAZ Metal Housing High Speed Metal Gear Digital Servo 35KG 180 Large Torque Waterproof for RC Car Crawler SCX10 TRX4
◊
x digital servo1x 25T adjustable metal servo arm1x accessory bag
Apply Environmental Conditon:1.Storage Temperature Range:-30°C~80°C2.Operating Temperature Range:-25°C~70°C3.Waterproof grade:IP66(Do not soak in water)
Mechanical Specification:1. Size: 54.2×20×46 mm2. Weight: 60g±2g3. Limit angle: 180°4.Bearing: 2BB5.Horn gear spline: 25T Diameter:5.9mm6.Case : Engineering plastics+Aluminum alloy7.Connector wire: 300mm±5mm8.Motor: Carbon brush motor
Electrical Specification:1.Working voltage range: 4.8-7.4V DC2.Command signal: Pulse width modification3.Amplifier type: Digital controller4.Pulse width range: 500～2500usec5.Neutral position: 1500usec6.Running degree: 180±3°(PWM 500～2500usec)7.Dead band width: 3 usec
